Advanced Processing EPE foam Sheet Making Machine With Different Colour
Product Description
This machine is mainly used to produce EPE sheet. Using LDPE granule, by process of heating, melting, extruding, curing, foaming and forming to stick, tube, U type, V type epe foam sheet foaming extruder and fruit net. its main features are noise and heat insulation, cushion protection, friction avoid, water, decay and moisture resistance, good elasticity, etc. It can make 0.5-25mm sheet and also can produce all kinds of packing and filling materials by coating or laminating.
These products are widely used to pack electron, electric equipment, arts, crafts, ceramic, lamp, computer products and furniture.
PE foam sheet extruder producing fine closed cell Polyethylene foam sheet, by our unique
designed Screw and Barrel system, using Butane foaming agent, Talc powder or Talc master
batch and Anti-shrinking agent (GMS for short-Surface Active Agent) by accumulated experience and advanced technology.
1. PE foam and related products are made from PE resin and it is expanded and formed into
shapes by being heated and extruded. And it is easy to be decompounded and environment
friendly.
2. Its key function is cushion protecting and warmth reserving.
3. Nowadays it is the most popularly used for modern batch production products, especially export
packaging industry, including electronic industry (such as PC computer, laptop, electronic chips
and parts, inverter, TV, air conditioner, refrigerator), furniture, glassware, garments, metal parts,etc.
4. Whoever aims at modern packaging and export, he has to use PE foam for the following
reasons: Packaging with air bubble film, EPS and plastic film is forbidden in many countries.
Paper packaging is so expensive.
5. PE foam products have quite a few varieties: Sheets for direct wrapping and to make bags;
PE sheet may be coated with plastic film, craft paper
and aluminum foil. It may be laminated (by electricity or LPG flame) into thick blocks. Then cut
them to make different containers or frames. PE fruit net is direct for fruit and small matter's
Main Parameters
| Parameters | Unit | Model |
| HR-90 | HR-105 | HR-120 | HR-150 | HR-170 |
| Products thickness | mm | 0.5-4.0 | 0.5-6 | 0.8-8 | 1-12 | 2-16 |
| Products width | mm | 1000-1200 | 1000-1400 | 1000-1800 | 1000-1800 | 1000-1800 |
| Installed power | kw | 90 | 100 | 120 | 150 | 180 |
| Installation Dimension | m | 22x2.5x2.2 | 23x2.5x2.2 | 25x2.2x2.2 | 30x2.5x2.2 | 32x2.3x2.2 |
| Cooling method | | Wind and water |
| Forming ratio | | 20-40 |
| Power supply | | 380V 50HZ 220V 60HZ
3 phase 380V50HZ 3 phase 220v 60HZ |
Applications:
I. Characteristics of Product
-- High resilience and buoyant effect.
-- Effective insulating capability.
-- Low thermal conductivity.
-- Negligent absorption and water permeability.
-- Chemical resistant.
-- Effective and safe to handle in installation application.
-- Non-toxic and environmental friendly
-- Fine round closed-cell cellular structure assure
-- Excellent flexibility.
-- 100% recyclable and reusable.
II. Applications of Product
-- External cushioning and packing material.
-- Packaging for high-grade goods, industrial electronic parts.
-- Construction materials for insulation
-- Educational material
-- Sport material
-- Life vest etc.
Our service
1. Engineers available to service machinery overseas.
2. The technical parameter can be set according to customer's requirement
3. During the cooperation period, any problem you meet, we will try our best to help you.
